无铅产品参照表

,

产品型号 Model	合金成分 Alloy components	固化温度与液化温度 Solidify and fluidity temperature	锡条 Bar	锡线 Solder wire
				单芯 Single-core	三芯 Three-core	实芯 Solid-core
LB(W)C07	Sn99.3Cu0.7	227-227	√	√	√	√
LB(W)C05	Sn99.5Cu0.5	227-227	√	√	√	√
LB(W)C30	Sn97Cu3	227	√	√	√	√
LB(W)S50	Sn95Sb5	240-243	√	√	√	√
LB(W)A30	Sn97Ag3	221-230	√	√	√	√
LB(W)A35	Sn96.5Ag3.5	221	√	√	√	√
LB(W)A40	Sn96Ag4	221	√	√	√	√
LB(W)A35C	Sn96Ag3.5Cu0.5	217-219	√	√	√	√
LB(W)A30C	Sn96.5Ag3Cu0.5	217-220	√	√	√	√
LB(W)A03C	Sn99.2Ag0.3Cu0.5	217-227	√	√	√	√
LB(W)A20C	Sn97.5Ag2Cu0.5	217-222	√	√	√	√
LB(W)A10C	Sn98.5Ag1Cu0.5	217-223	√	√	√	√
LB(W)A35C	Sn95.7Ag3.5Cu0.8	217-219	√	√	√	√
LB(W)A35B	Sn91.6Ag3.5Bi4.9	205-210	√	√	√	√
LB(W)Z90	Sn91Zn9	199	√
LB(W)B580	Sn42Bi58	139	√
LB(W)Z80B	Sn89Zn8Bi3	190/197	√
LB(W)I520	Sn48In52	118	√
绿色块为公司主流产品，黄色块和蓝色块根据客户需求商定后供货，蓝色块为低温产品。 Green area is popular products in stock,yellow and blue areas are supplied according to the customer’s demand,blue area is low temperature products.
